Screwed End Ball Valve

Screwed End Ball Valve – 3 Piece Body, Full Bore

Designed for robust performance in compact piping systems, the Screwed End Ball Valve offers exceptional flow control and sealing integrity. Its 3-piece body design ensures ease of maintenance, while full bore construction minimizes flow restriction.

Key Specifications

Type: 3 Piece Body / Full Bore

Size Range: 15 mm to 50 mm (1/2″ to 2″)

Body Material: WCB, CF8, CF8M, CF3, CF3M

Ball Material: AISI 316, CF8M, CF3M

Seat Material: PTFE / RPTFE

End Connections: BSP(F), BSP(T), NPT, Socket Weld

Stem Material: ASTM A182 SS304 / SS316

Operation Options: Lever, Pneumatic Actuator, Electric Actuator

Temperature Range: –29°C to +200°C

Pressure Rating: Class 1000 (WOG)
